VAPORBLOCK ® 10 & 15 mil

VAPORBLOCK® Series consist of high-performance underslab vapor barriers designed to retard moisture migration through concrete slabs. This product is made from state-of-the-art polyethylene resins that provide superior physical and performance properties that far exceed ASTM E-1745 (Plastic Water Vapor Retarders Used in Contact with Soil or Granular Fill Under Concrete Slabs) Class A, B and C requirements.

High tensile strength, unequaled puncture resistance, ultra-low moisture vapor permeability as well as resistance to decay make VaporBlock one of the most effective underslab vapor barriers on the market today! Available in 10 and 15 mil thicknesses to best meet required performance specifications.

Download PI Sheet





Product Features

  • Ultra-low moisture vapor permeability
  • Superior puncture resistance
  • High tensile tear strength
  • Resistance to decay and degradation

Applications

  • Underslab Vapor Retarder/Barrier
  • Foundation Wall Vapor Retarder
  • Radon Retarder
PROPERTIESTEST METHODVAPORBLOCK VB10VAPORBLOCK VB15ASTM E 1745-11
Class A, B & C
Appearance-BlueBlue-
Thickness, nominal-10 mil15 mil-
Roll Size-14 ft x 210 ft14 ft x 140 ft-
Weight-42 lbs/MSF69 lbs/MSF-
ClassificationASTM E1745CLASS A, B, & CCLASS A, B, & CClass A, B, or C
Tensile Strength
Average MD & TD
(New Material)
(After Exposure)		ASTM E154
Section 9, (D882)		52 lbs/in

53 lbs/in		60 lbs/in

61 lbs/in		Class A = 45 lbs/in
Class B = 30 lbs/in
Class C = 13.6 lbs/in
Minimum
Puncture Resistance (Typicals)ASTM D1709
Method B		2200 g2600 gClass A = 2200 g
Class B = 1700 g
Class C = 475 g
Minimum
Permaeance (New Material)

(After Conditioning)		ASTM E154
Section 7
ASTM E96
Procedure B

ASTM E154
Section 8, E96
Section 11, E96
Section 12, E96
Section 13, E96		0.0146
Perms
grains/(ft²•hr•in Hg)
0.0153
0.0151
0.0160
0.0181		0.01
Perms
grains/(ft²•hr•in Hg)
0.01
0.01
0.01
0.01		Class A, B, & C
0.1
Perms
grains/(ft²•hr•in Hg)
Maximum
WVTRASTM E96
Procedure B		0.0084
grain/hr-ft²		0.004
grain/hr-ft²		-
Maximum Static Use Temp-180° F180° F-
Minimum Static Use Temp--70° F-70° F-
